AW 300 M er Electrocompaniets nyeste Mono Forsterker. Denne forsterkeren innehar et oppdatert, men umiskjennelig Electrocompaniet-design, som komplementerer både nåværende og eldre Electrocompaniet-produkter.
Input impedance: 330 kΩ |
Frequency resp. (in. filter active):0.5 – 220 kHz |
Frequency resp. (in. filter dis.): 0.5 – 1.1 MHz |
Voltage gain (mono, bal. input): 29 dB (x28) |
Input-referred noise (20-20kHz): < 2 μV |
SNR (ref. 1W/8Ω load, 20-20 kHz): 95 dB |
SNR (ref. full power out, 20-20 kHz): 120 dB |
Slew-rate (input filter disabled): 140 V/μs |
DC output voltage: < 5 mV |
THD+N: 0.0006 % |
IMD: 0.001 % |
Damping factor (8Ω load): > 1000 |
Power consumption standby: < 0.5W |
Protection: DC, overload, temperature |
|
RATED OUTPUT POWER MONO: |
8Ω load: 300 W |
4Ω load: 600 W |
2Ω load: 1000 W |
WEIGHT & DIMENSIONS: |
Weight: 30 kg – 66.13 lbs |
Width: 212 mm – 8.34 inches |
Depth: 488 mm – 19.21 inches |
Height: 292 mm – 11.49 inches |
*Features and specifications are subject to change without further notice. |
